State/LED Arm/Disarm Fault Area System Fault Tamper Fault Intruder Fault
Colour Green Green Yellow Red Red
1.3 The Transmitter Function
The Domonial CMI800++ panel is equipped with a digital transmitter for sending information to the
following, via PSTN, GSM (GESEM835IS, GPRS800***, ETH800 expansion card) or ADSL :
► A telephone (PSTN, GSM voice).
► An Alarm Receiving Center using the following protocols: Secom3, Surtec, Cesa, Contact ID
Please note: Data networks, such as GSM Data or GPRS, use the SECOM3 protocol.
PSTN
ADSL (optional)
GSM (optional)
GPRS (optional)
Remote maintenance &
programming (DomoPC)
Audio
Audio-visual
*** Panels pre-equipped with the GPRS module only.
This product is in conformity with applicable requirements of the directive 1999/5/CE: EMC
Directive 89/336/EEC, R&TTE Directive 99/5/EC and Low Voltage Directive 73/23/EEC.
