Sensors MOTION DETECTORS
IS280CM
360° Ceiling Mount PIR
• Range: 45' dia. @ 10' mounting height
50' dia. @ 12' mounting height
• Mounting heights from 8' to 12'
• Low profile housing
• Microprocessor-based signal processing
• Sealed optics chamber
• Can be mounted on a single gang-box
• Cover tamper
• Selectable pulse count
• Dual Slope Temperature Compensation
PIRs – CEILING MOUNT
997
Ceiling Mount PIR Motion Sensor
• Up to 36' (11m) diameter coverage pattern
• 360˚ look-down capability
• 8' to 12' mounting height
• Twist off cover for easy removal
• Locally and remotely controllable walk
test LED
• Selectable pulse count
13 ft
(4m)
7 ft
(2.1m)
3 ft
(0.9m)
22 ft
(6.7m)
16.25 ft
(4.95m)
8.75 ft
(2.67m)
3.75 ft
(1.14m)
27.5 ft
(8.4m)
0
13 ft
(4m)
22 ft
(6.7m)
16.25 ft
(4.95m)
27.5 ft
(8.4m)
3 ft
(0.9m)
3.75 ft
(1.14m)
7 ft
(2.1m)
8.75 ft
(2.67m)
10 ft
(3.1m)
8 ft
(2.4m)
EDCBA B
C
DE
Top View
Top View
