Detector 1-5: Range (On & Off Sensitivity) Max: 100%, 75% or 50% / High: 100%, 75% or 50% / Med: 100%, 75% or 50% / Low: 100%, 75% or 50% / Min: 100% or 75%
Detector 1-5: Sensitivity Fine
Mode A, Mode B or Mode C - Applies when Sensitivity is set to Max and during occupancy only (Mode A = Normal, B & C = More Sensitive)
Common: Address
0-127 - MLS address for DALI Emergency test. Default = 0
Common: Switch Map
Normal / Direct / Direct 2 / Zero Off Dly / Modes 04-07 (for future use) - Pre-set switch mappings (except Zero Off Dly - instant off option)
Common: LED Inhibit
Yes / No - Enab les or disab les the detector’s LEDs.
Common: Inhibit DALI Init
Yes / No - Prevents the DALI b allasts from being initialised every time the box powers up.
Common: Missing Detector
Normal / On Full - Puts all outputs on if there’s a detector assigned to a channel and that detector isn’t present.
Common: Slow Dim (mins )
0-254 - Fade time setting, for use with Slow Dim and Slow Brighten switch functions. Default = 0
Common: Bus Absent All On
Yes / No - All lights default to ON in the event of a b us failure.
Assigned Detectors Detector 1 - Detector 5 Assigned or Not Assigned to this Channel.
Pcell Source
None (--), 1,2,3,4,5 - Photocell 1-5 (in Detectors 1-5) Assigned or Not Assigned to this channel.
Assigned Switches Switch 1A - Switch 5B & Switch 6A - 7B (RF) Assigned or Not Ass igned to this channel.
Power Up
On / Off
Occ Trigger Mode
Presence / Absence / Manual
Low Lux Level (Auto Absence)
0-254 (0 = feature disabled) - Used in manual modes: When it is dark, lights respond to movement automatically without requiring switch press.
Sw Auto Detect
Yes / No - Used in manual modes: If set to Yes, presence detection is automatic until a switch press is detected.
Manual I/P
Local / Share (Local = Obey locally only; Share = Obey locally and trasmit command on MLS bus)
Occupied Scene
Scene 1-6 Scene1
Alt. Occ. Scene A & B
Scene 1-6 or -- (feature disabled) - Determines different actions on entry dependent on time of day.
Start Lamps
Max / Min
Occupied Timer
10 seconds to 96 hours, Disabled. 20 mins
Photocell
Regulate (100%, 90%, 80%, 70%, 60%, 50%) / Pas sive / Active / Disabled
Bright Out
Yes / No
Set-Point Low / High
Photocell Lower and Upper Thresholds: 0-1023 (used in Regulating Scene 1). Low = 350; High = 450
Scene 2-6
Output 0-100% or -- (no change) Scene 2 = 80%; 3 = 40%; 4 = 20%; 5 = 10%; 6 = 5%
Transition Scene
Scene 1-6 or -- (feature disabled) - Scene interposed between 'Occ Timer' & 'Background Level' to allow movement to restore lights at existing level.
Transition Timer
10 seconds to 96 hours - Determines length of transition scene. 10 secs
Background Level Off
Minimum, 25% or Scene 6 (these options show XTN suffix) for 3 x Occupied Timer, then Off.
Minimum, 25% or Scene 6, 5, 4, 3 or 2 (these options show BLD suffix) until the building has been vacated.
Minimum, 25% or Scene 6, 5, 4, 3 or 2 (Background Timer parameter applies to these options which have no suffix).
Alt. Background Scene A & B
Scene 1-6 or -- (no scene) - Determines different actions when the area is vacant dependent on time of day.
Background Tmr
10 seconds to 96 hours or -- (none) - Applies to 'Alt Exit Scenes' and some 'Background Level' scenes (i.e. not XTN and BLD options). When Background Timer
expires, channel's output turns off.
Fade to Off
Yes / No
Bus Connect
Yes / No
Zones 1-4
None (--), Zone number 1-100 / Common 1,2,3
Zones 1-4 TRX
Tx Rx / Tx Only / Rx Only - Determines how zone parameters 1-4 behave with respect to bus commands.
Corridor 1-2: Begin / End
None (--), Zone number 1-100 / Bld
Corridor Scene
Scene 1-6 or -- (no scene) - Movement within an area's Corridor Begin/End span will cause that area to go to the chosen scene. Direct movement within zones 1-4
will override this and the channel will go to its Entry Scene.
Global 1-2 Rx
Yes / No
Ballast
1% DSI, 3% DSI, 10% DSI, 1% DALI, 3% DALI, 10% DALI (Non-Dimming - use default i.e. 1% DSI)
Lamp Max
100%, 90%, 80%, 70%, 50%, 45%, 40%, 35%, 30%, 25%, 20%, 15%, 10%
Burn-In Hrs
Burn-in 100 hrs / Cancel / Resume (See Application Note AN4028 - limited functionality via QuickSet Pro)
Quick Burn-In
Yes / No - If set to Yes, output rem ains on until 100-hr b urn-in is completed.
Burn-In Dimming
Yes / No - If set to Yes, allows temporary (30 secs) dimming in response to manual inputs, even though in 100-hr burn-in mode.
Offset Dimming None (--) to 100% in 10% increments. Allows selected channels to be configured to be brighter than a reference channel according to chosen 'output weightings'
(e.g. Ref Ch = 0% (window row), Ch2 = 10% brighter (adjacent to window row), Ch3 = 30% brighter (furthest from windows) - all would work together to achieve
chosen lux level, maintaining respective percentage differences in output).
Per Channel Parameters:
Simple momentary push-to-make walls witch that can be used to raise or lower the lighting level or toggle the output of the unit ON or OFF. Short pres s toggles
output level between ON & OFF, long press will ramp the light level Up or Down.
On-Dim Short Press will turn the output ON, long press will lower the light level.
Off-Brighten Short Press will turn the output OFF, long press will raise the light level.
On / Brighten Short Press will turn the output ON, long press will raise the light level.
Off / Dim Short Press will turn the output OFF, long press will lower the light level.
Emergency Tst Imitates manual test of emergency luminaire by turning OFF the Maintained Live.
Emergency End Restores Maintained Live to end the Emergency Test.
Last Out "Las t man out" s witch, reduces the Occupied Tim er to 10 seconds for a fast tim e-out when leaving the building.
Door Open / Door Closed Connected to switches detecting whether door is open or closed. Choice depends on type of operation (normally contact would be closed when door is closed).
Keycard In / Keycard Out Connected to switches detecting whether keycard is inserted or not. Choice depends on type of operation.
Edge: On, Off, Scene 1-6 Edge-triggered commands as above - sent only once as the switch is pressed.
Edge: Brighten / Dim Each press increments or decrements the DALI output.
Last Out-On Short press = fast time-out for "last man out"; Long pres s = turns on at Entry Scene for "first man in".
Time of Day A & B Cause the channels to use Alt. Occupied Scenes A or B and Alt. Background Scenes A or B.
Unoccupied 10% Sends a 'Time Out Now, Go to DALI 10%' message on the MLS bus.
Partition Open / Closed Initiates logical partition of a room - for use with EnOcean reed switch transmitters.
Slow Brighten / Dim Switch input held causes slow ramp / slow fade. Fade time adjustable in Com mon menu, 1 min to 254 mins.
