DISTRIBUTED I/O
Control Products Control Products Control Products
Honeywell Inc. Honeywell Limited-Honeywell Limitee Honeywell AG
Honeywell Plaza 155 Gordon Baker Road Böblinger Straβe 17 Manufacturing
P.O. Box 524 North York, Ontario D-71101 Schönaich location certified to
Minneapolis, MN 55408-0524 M2H 3N7 Germany
USA Canada http://europe.hbc.honeywell.com
EN0B-0090GE51 R0802 / 74-2145-2 printed in Germany Subject to change without notice
electronic module
(XFL521x, 522x,
523x, 524x)
manual
override
module
(XFR522,
XFR524)
6-27/64 inches (163 mm)
with manual disconnect module and manual override module
5-43/64 inches (144 mm)
with manual disconnect module
4-41/64 inches (118 mm)*
XSL511
*The maximum length of 4-41/64 inches (118 mm)
is attained when the
XSL511 LON Connector is attached.
Fig. 40. Outside dimensions of XSL513/514 terminal blocks and mounted modules (side view)
Fig. 41. Dimensions of XSL511 LONWORKS connector module in inches (mm)
