Galaxy Flex Installer Manual Program Outputs [53]
129
It provides a system status indication during unsetting and setting. The indicated states
are as follows:
General Alarm On 500 ms. Off 500 ms
Clear to Exit Continuous
Exit interrupted On 100 ms. Off 100 ms
75% Exit Time On 200 ms. Off 200 ms
Set On 600 ms. Off 600 ms (twice)
Normal Entry On 800 ms. Off 200 ms
75% Entry Time On 200 ms. Off 200 ms
Fire ON 500 ms. Off 100 ms
Chime ON 500 ms. Off 400 ms (twice)
19 Part Set (Reflex)
This output is activated when the assigned groups on the system are part set. This output is a
Reflex output and follows the part set and unset status of the groups.
20 Confirm (Latch)
This output is activated when there have been activations in two separate zones. The second
activation must occur within the Confirm Time Window. The zones do not have to be in the
same group, however, both groups must be assigned to the Confirm output to allow
activation. Cross-group confirmation is controlled by the Communications programming in
ARC Notify [56.1]. If signalling is by DTMF format, cross-group confirmation occurs on
groups that share the same confirm channel. In all other signalling formats, cross-group
confirmation occurs on groups that share the same account number.
Note: The Confirm output is used to give positive identification that a genuine intruder
alarm condition has occurred and to minimise the possibility of false alarm
activations.
21 Line Fail (Reflex)
This output is activated whenever a Line Fail zone is active or the telecom module detects
and sustains a line failure for more than 30 seconds.
22 Video (Pulse)
This output is activated by the Video zone when the system is set, and can be used to
activate video recorder or video transmission systems.
23 Comm Fail (Latch)
This output is activated whenever there is a communication failure on the telecoms module
telephone line. A fail to communicate event overrides the remaining Bell Delay period.
