Appendix G: Peripherals Galaxy Flex Installer Manual
226
SIM cards
Any valid GSM SIM card can be used. We recommend a contract type for systems with
alarm signalling to avoid a situation where credit may run out, resulting in a loss of
signalling capability. Use a data enabled SIM card if you intend to use the GSM channel for
remote servicing. Most service providers can supply this service on contract SIMs and will
issue a separate data number. Use this data number for remote servicing when dialling into
the panel.
Programming
Program the module using the GSM or GPRS menu in the control panel (option 56).
Characteristics
The following table shows the technical characteristics of the GSM module:
GSM fault detection Dedicated internal GSM fault code
is triggered by the lack of a
network
Service temperature -10 to +40°C
Storage temperature −20°C to +70°C
Dual band GSM 900 MHz and DCS 1800 MHz
Humidity 25% to 55%
Product weight (packaged) 450g
Dimensions (packaged) L 192 mm x W 85 mm x D 85 mm
Nominal voltage 15 V
Power 2 W (GSM)/ 1W (DCS)
Quiescent current 35 mA
Alarm current 150 mA*
for 30 seconds (typical)
Antenna Supplied
SIM card Micro
Encryption (GPRS only) AES128 Bit
* Average current during normal alarm transmission.
Compliance
This product is suitable for use in systems designed to comply with EN50131-1, EN50136-1
and PD6662:2004 & 2010.
Security Grade – GSM – 2(GSM), 3(GPRS)
Environmental Class – II
Alarm Transmission System GSM ATS2=D2, M2, T2, S0, I0
GPRS ATS5=D3, M3, T4, S2, I3
Prevention of substation, according to EN50136-1, is achieved using encryption of account
number and messages to and from the ARC combined with the ability of the CIE to detect
unauthorised removal and addition of devices to the databus.
