Honeywell HN Series User Manual

6
1) Timer Control / Sleep Control 4) Mode Control
2) Fan Speed Control 5) Power Control
3) Timer / Temperature Set Controls 6) Indicator Lights
USE & OPERATION
CONTROL PANEL
o
C
o
F
COOL
DRY
FAN
HEAT
POWER
TIMER
SLEEP
WATER
FULL
HIGH
MID
LOW
TIMER
SLEEP
o
C
o
F
COOL
DRY
FAN
POWER
TIMER
SLEEP
WATER
FULL
HIGH
MID
LOW
TIMER
SLEEP
(2) (4) (3) (1) (6) (5) (2) (4) (3) (1) (6) (5)
Model with Heat Mode Model without Heat Mode
FUNCTION BUTTONS
The Power Control turns the unit on and off. When the unit is plugged into an appropriate electrical
outlet, the POWER indicator light will illuminate red indicating the unit is in a Standby Mode, ready
to be switched on at anytime. The air vent will automatically open when the unit is turned ON and
automatically close when unit is turned OFF.
POWER CONTROL
The Timer is adjustable between 1 - 24 hours.
AUTO TURN OFF:
While unit is running, press the TIMER button and the display will flash. While the display is
flashing, press the + or - button to select the number of hours you want the unit to turn OFF
automatically.
AUTO TURN ON:
When unit is in a standby mode (plugged in with power light on), press the TIMER button and the
display will flash. While the display is flashing, press the + or - button to select the number
of hours until you want the unit to turn ON automatically.
TIMER CONTROL
TEMPERATURE CONTROL
Used for adjusting the timer and thermostat.
The default display is setting temperature.
In cooling mode, when + or - button is pressed, the set temperature is displayed and may be
adjusted. After 5 seconds the display will revert back to room temperature.
Note: By pressing both + / - buttons at the same time, the display will toggle between Celsius(°C)
and Fahrenheit(°F).
•
•
•
