INSTALLATION
It is important that the installation instructions below are followed for successful installation of this
Local Air Conditioner. Please call Customer Support if you have any difficulties or queries regarding
these installation procedures.
Installation Kit:
Installation Steps:
Exhaust Hose Connector, Exhaust Hose and window bracket panel adapter are pre-assembled
inside the package.
1.
4 6
x1
x1 x1
5
Hose:
Length: 9.8'' to 59'' (25cm to 150cm)
1 2 3
x1 x2
x1
1. Window bracket kit (1 Set) 4. Exhaust hose (1 Piece)
2. Butterfly screws (2 Piece) 5. Window bracket panel adapter (1 Piece)
3. Drain tube
(Dehumidifier mode)
(1 Piece) 6. Exhaust hose connector (1 Piece)
To Next Page
