Honeywell HWBL1023 Series - INSTALLING YOUR WATER COOLER FOR THE FIRST TIME

1 2
12
13
14
15
17
16
11
8
5
6
7
3
4
9
10
No Name
1 Hot Water Tap
2 Room Temperature Tap
3 Cold Water Tap
4 Safety Lock
5 Indicator Lights
6 Faucets
7 Drip Tray
8 Water Bottle Pump Connection
9 Reset Button
10 Cabinet Door
11 Water Bottle
12 Cold Switch (Green)
13 Hot Switch (Red)
14 Rating Label
15 Condenser
16 Power Cord
17 Drain Cap
No Name
2. PARTS AND FEATURES
