Shock sensor
Installation requirements
The SHK(C)8M series is designed to protect window and door surroundings, and is used
to detect forcible attacks upon the surface on which it is mounted.
It is capable of detecting two different types of forcible attacks:
Strong attack: the device will send an alarm for any single shock event whose
intensity exceeds the factory set strong attack sensitivity level
Repeated attacks: the device will send an alarm after a defined number
(controllable) of consecutive shocks, whose intensity exceeds the factory set
repeated attack sensitivity level detected within a period of 8 s
How to install
1. Remove the cover of the sensor.
2. Mount the sensor on a solid surface with the screws
supplied. There are two mounting holes.
3. For SHKC8M only, mount the magnet (supplied)
adjacent to the sensor’s alignment strip.
