Indoor siren
Installation requirements
Install the siren:
Away from any source of electrical interference
On a ceiling or as high as possible on a wall
Centrally, within the protected premises
How to install
1. Remove the cover.
2. Position the siren base plate against the wall and mark the
3 securing holes.
3. Drill the holes, insert the screw anchors, and then screw
on the base plate.
4. Pull out the battery tab to power up the sensor.
5. Press the black button on the PCB. You will hear 2 short
beeps from the Badge reader and the siren.
6. Locate the cover onto the tab (1) on the base, and then
turn to the other side (2).
