Ready To Arm
5200-100-062-V0
Name
Save
Type
Trigger Output
01
Start Zone Type
Not Used
Start System Operation
Not Used
Action
None
Stop Zone Type
Not Used
Stop System Operation
Not Used
9. Select “Stop Zone Type” The system displays the same
options as the previous step.
Note: If a Rule is being used to trigger a Z-Wave door lock, when
the system is Armed Stay or Armed Away, it is
recommended that “End of Exit Delay” be selected for
System Operation 1 or System Operation 2.
10. Select “Start System Operation”. Use the “S” “T” buttons to
scroll to second page of zone type options. The following
options are displayed:
Not Used Arm Stay
Arm Away Disarm
Any Burglary Alarm Any Fire Alarm
Bell Timeout End of Exit Delay
Start of Entry Delay Chime
Kissoff Bypass
System Low Battery Reporter Failure
Duress Alarm
11. Select “Stop System Operation”. The system displays the
same options as step 10.
Ready To Arm
5200-100-063-V0
Save
Zone Number Operation
Not Used
12. Select “Zone Number Operation”. The system toggles
between the following options:
Not Used
Fault
Trouble
Alarm
Notes: 1. For Fault, the following zone types should not be used:
General Monitor, General Response, Resident
Monitor, and Resident Response.
2. When a zone has been deleted, please verify the
programming selection for Zone Number Operation.
If Trouble, Fault or Alarm is selected, the system displays
several new options. Proceed to Step 13.
Ready To Arm
5200-100-064-V0
Save
Third Start Zone
Disabled
First Start Zone
Disabled
Second Start Zone
Disabled
Zone Number Operation
Fault
Third Stop Zone
Disabled
First Stop Zone
Disabled
Second Stop Zone
Disabled
13. Select the First, Second or Third “Start Zone” Select the Zone
from the list displayed by the system.
14. Select the First, Second or Third “Stop Zone” Select the Zone
from the list displayed by the system.
15. Select “Save” when programming is complete.
16. Select the “2” button. The system returns to the Automation
programming screen.
To Next Page
