Honeywell Lyric T5 W - Installing the Lyric T5 Thermostat (Continued); Attach Thermostat Unit; Turn Power ON; Return to Thermostat for Setup

14 15
16 Turn your power ON
Turn on the power at the breaker box
or switch that controls the heating/
cooling system.
OFF
ON
ON
OFF
ON
ON
15 Attach your thermostat
Align the thermostat onto the
UWP and firmly snap it into place.
17 Return to the thermostat
Return to the thermostat. Confirm the
screen shows START SETUP. If it does,
continue to “Setup with Lyric App” on
page 15.
If your thermostat does not show
STAR T SE TUP, please contact
Honeywell support.
Breaker box
Switch
