4
INSTALLATION (CONTINUED)
2. The Window Brackets are approximatley 19.7" (50 cm) each, allowing you to install to windows
and balcony doors of different heights or width.
Adjustable Knobs
EN
19.7" (50 cm)
1 part
19.7" (50 cm) to
38.2" (97 cm)
2 parts
47.2" (1.2 m)
3 parts
3. Connect the Exhaust Hose to the rear exhaust outlet on the back of the unit. Slide-in the Hose
Connector from up to down.
Note: After setting the window bracket to the size of your window, please remove it from the window
and follow the instructions below.
To install the window bracket to the window frame, you need to adjust the height or width of the
window bracket by extending the length according to the height or width of the window. When the
length is set, tighten the Adjustable Knobs (preinstalled on the window bracket) to ensure the window
bracket is secured in the desired position. Use one or all three pieces of window bracket as needed.
To Next Page
