Appendix B — Wireless and Wired LAN
44 MP Compact4 Mark III User Guide
Set Up Wireless Infrastructure
After a successful setup is made via a wired connection, the wireless
connection (if equipped) can now be configured in infrastructure mode using a
static or DHCP issued IP address.
1 Open your web browser.
2 Type in the IP address of the printer. The default IP is: 192.168.10.26.
3 Click on Wireless Ethernet Settings on the left side of the screen. Locate
and set the following items:
• In the Acquire Address Method section, select the Use DHCP radio
button.
For static IP setup:
• In the Acquire Address Method section, select the Use Static
Addresses radio button.
• In the Static IP Addresses section, enter valid static IP addresses for
Printer IP Address, Printer Subnet Mask, and Printer Gateway.
Note: If a different IP Address has been assigned to the printer, make sure to
enter the correct IP address.
