F76S WATER FILTERS AND MV876B AUTOMATIC-BACKWASH CONTROLS
62-3015—410
F76S REPLACEMENT PARTS LIST (SEE FIG. 13)
PARTS AND ACCESSORIES FOR NEW STYLE F76S FILTERS:
N/A = Part number not available at time of printing.
a
Sold in packs of ten.
Description 1/2 inch 3/4 inch 1 inch 1-1/4 inch 1-1/2 inch 2 inch
(A) Pressure Gauge (new style F76S only)
Standard Pressure (230 psi) M76K-200 M76K-200 M76K-200 M76K-200 M76K-200 M76K-200
High Pressure (400 psi) M76K-400 M76K-400 M76K-400 M76K-400 M76K-400 M76K-400
(B) Tailpieces (same for new and old style)
Sweat U76S5007 U76S5015 U76S5023 U76S5031 U76S5039 U76S5047
Threaded (shown) U76T1004 U76T1014 U76T1022 U76T1030 U76T1038 U76T1046
(C) Union Nuts N/A N/A N/A N/A N/A N/A
(D) Tailpiece Gaskets (sold in packs of 10) 0901444 0901444 0901445 0901446 0901447 0901448
(E) Guide Barrel N/A N/A N/A N/A N/A N/A
Screen Insert Complete (new style only)
20 Micron AF11S-1B AF11S-1B AF11S-1B AF11S-1B AF11S-112B AF11S-112B
50 Micron AF11S-1C AF11S-1C AF11S-1C AF11S-1C AF11S-112C AF11S-112C
100 Micron AF11S-1A AF11S-1A AF11S-1A AF11S-1A AF11S-112A AF11S-112A
200 Micron AF11S-1D AF11S-1D AF11S-1D AF11S-1D AF11S-112D AF11S-112D
Includes:
(F) Barrel O Ring
(G) Impeller and Screen Assembly
(J) Chamber O Ring
(H) Base Spring N/A N/A N/A N/A N/A N/A
(J) Chamber O Ring (sold in packs of 10) 0900747 0900747 0900747 0900747 0900748 0900748
Filter Sump Kits (new style only)
Clear Plastic KF11S-1A KF11S-1A KF11S-1A KF11S-1A KF11S-112A KF11S-112A
Bronze FT09RS-1A FT09RS-1A FT09RS-1A FT09RS-1A FT09RS-112A FT09RS-112A
Includes:
(J) Chamber O-Ring
(K) Sump
(L) Ball Valve O-Ring
(M) Integrated Ball Valve
(N) Memory Ring
(P) Ball Valve Bowl
(Q) Ball Valve Knob
(R) Joint Ring Seal
(S) Drain Connector
Ball Valve Assembly (new style only)
Includes:
(M) Ball Valve
(L) Ball Valve O-Ring
KH11S-1A KH11S-1A KH11S-1A KH11S-1A KH11S-1A KH11S-1A
Sump Wrench ZR10K-34 ZR10K-34 ZR10K-1 ZR10K-1 ZR10K-112 ZR10K-112
