68-0173—34
Fig. 2. Dimensions for 205224A Wall Cover
Plate in in. (mm).
Fig. 3. Dimensions for C7089A Outdoor Sensor
Mounting Clip in in. (mm).
Fig. 4. Dimensions for C7100A Discharge Air Sensor in in. (mm).
Fig. 5. Dimensions for C7189A Remote Indoor Sensor in in. (mm).
M7513
3-1/4 (83)
8-1/2 (216)
7/8
(22)
7/8
(22)
6
(152)
M4488
1-1/2 (38)
3/4
(19)
13-1/4 (336)
1-3/16
(30)
1-3/16
(30)
1-13/16
(46)
1-13/16
(46)
M4461
M4465
4-5/8
(117)
4-5/8
(117)
2-3/4 (70)
2-3/4 (70)
1-1/8
(29)
FRONT VIEW SIDE VIEW FRONT VIEW (COVER OFF)
3-1/4
(83)
