Honeywell PRO22IC Specifications

SPECIFICATIONS
3
www.honeywell.com/security/uk
PRO-2200 Series Single Reader
Modules (PRO22R1)
Module Specifications:
• 1 Reader port - 12 VDC at 50 mA,
clock / data or data0 / data1
• Keypad multiplexed with card data
• Two-wire or one-wire bi-color LED
support
• Buzzer support only with one-wire
LED control
• 2 supervised, general purpose alarm
inputs with programmable circuit type
• 1 dedicated alarm input for tamper
detection
• 1 general purpose output relay,
form-C, 5A 28 VDC
• 1 general purpose output relay,
form-C, 1A 28 VDC
• To be used only with the PRO22ENC4
enclosure
Alarm Input Properties:
• Inputs may be assigned to door
related functions or general purpose
I/O
• Circuit type – normally open, normally
closed, non-supervised, supervised
(with standard 1K or custom end-of
line resistance 200-10K)
• Line conditioning – programmable
sensitivity and hold time
Output Control Properties:
• Outputs may be assigned to door
related functions or general purpose
I/O
• The 5A relay(s) are rated to handle
the inductive loads of door locking
devices
• The 1A relay is rated to handle dry
circuit logic
• Configurable as standard (energize to
activate) or fail-safe (de-energize to
activate)
• Pulse control – single pulse (up to 24
hours) or repeating pulse (on/off in
0.1 second increments, up to 255
times)
PW-Series Dual Reader Module
(PRO22R2)
Module Specifications:
• 2 Reader ports - 12 VDC at 50 mA,
clock/data or data0/data1
• Keypad multiplexed with card data
• Two-wire or one-wire bi-color LED
support
• Buzzer support only with one-wire
LED control
• 8 supervised, general purpose alarm
inputs with programmable circuit type
(only 6 available when using
PRO22ENC1, PRO22ENC2 and
PRO22ENC5 enclosures)
• 2 dedicated alarm inputs for tamper
detection and power loss
• 2 general purpose output relay,
form-C, 5A 28 VDC
• 4 general purpose output relay,
form-C, 2A 28 VDC (only 2 available
when using PRO22ENC1,
PRO22ENC2 and PRO22ENC5
enclosures)
Alarm Input Properties:
• Inputs may be assigned to door
related functions or general purpose
I/O
• Circuit type – normally open, normally
closed, non-supervised, supervised
(with standard 1K or custom end-of
line resistance 200-10K)
• Line conditioning – programmable
sensitivity and hold time
Output Control Properties:
• Outputs may be assigned to door
related functions or general purpose
I/O
• The 5A r
elay(s) are rated to handle
the inductive loads of door locking
devices
• The 1A relay is rated to handle dry
circuit logic
• Configurable as standar
d (energize to
activate) or fail-safe (de-energize to
activate)
• Pulse control – single pulse (up to 24
hours) or repeating pulse (on/off in
0.1 second incr
ements, up to 255
times)
PRO-2200 Series Sixteen Relay
Output Module (PRO22OUT)
Module Specifications:
• 2 dedicated alarm inputs for tamper
detection and power loss (tile-
m
ounted only)
• 12 general purpose output relays,
form C, 2A 30 VDC (16 are available
when using PRO22ENC3 tile-
mounted enclosure)
Output Control Properties:
• All 16-relay outputs in the tile-mount
configuration (12" rack-mount) are
available for general purpose I/O
• The 2A relays are rated to handle dry
circuit logic
• Pulse control – single pulse (up to 24
hours) or repeating pulse (on/off in
0.1 second increments, up to 255
times)
• Configurable as standard (energize
to activate) or failsafe (de-energize to
activate)
PRO-Series Sixteen Alarm Input
Module (PRO22IN)
Module Specifications:
• 2 dedicated alarm inputs for tamper
detection and power loss (tile-
mounted only)
• 16 general purpose inputs with
programmable circuit type
• 2 general purpose, form C, 2A 30
VDC relays (only one available when
using PRO22ENC1, PRO22ENC2
and PRO22ENC5)
Alarm Input Properties:
• All 16 inputs may be assigned to
door related functions or general
purpose I/O
• Circuit type – normally open,
normally closed, nonsupervised,
supervised (with correct EOL)
• Line conditioning – programmable
sensitivity and hold time
Output Control Properties:
• Both relay outputs are available for
general purpose I/O and rated to
handle dry circuit logic
• Pulse control – single pulse (up to 24
hours) or repeating pulse (on/off in
0.1 second incr
ements, up to 255
times)
COMMUNICATION SPECIFICA
TIONS
Module Specifications:
Communication Features:
• RS-485 port, 4000 feet / 1,250 meters
total bus length
• Standard speed is 38.4 KBps
PRO-2200 Access Modules (PRO22R1) (PRO22R2) (PRO22OUT) (PRO22IN)

Honeywell PRO22IC Specifications

General

Brand	Honeywell
Model	PRO22IC
Category	Controller
Language	English
