Honeywell PRO22IC Specifications

PRO-2200 Series Access Modules
ORDERING
HAS-PRO2200M-01-EN(0807)DS-LD
August 2007
© 2007 Honeywell International, Inc.
Honeywell Access Systems UK
Charles Avenue
Burgess Hill
West Sussex.
RH15 9UF
01444 251180
01444 871074
www.honeywell.com/security/uk
For more information: www.honeywell.com/security/uk
Order # Description
PW-2200 Controllers
PRO22IC
PRO-2200 Intelligent Controller
PRO22R1 PRO-2200 Single Reader Module
PRO22R2 PRO-2200 Dual Reader Module
PRO22OUT PRO-2200 Sixteen Relay Output Module
PRO22IN PRO-2200 Sixteen Alarm Input Module
PRO22EN PRO-2200 Network Interface Module
PRO-Series Enclosures
PRO22ENC1
(W
all-mount) Capacity: Nine modules. Power supply and battery not included
PRO22ENC2 (19" Rack-mount) Capacity: Nine modules. Power
supply and battery not included
PRO22ENC3 (Tile-mount) Capacity: Two modules. Power supply and battery included
PRO22ENC4 (Tile-mount) Capacity: One module (PRO22R1 only). Power supply and battery included
PRO22ENC5 (Cage only for custom enclosur
es) Capacity: Nine modules. Power supply and battery not included
Optional Accessories
PRO22DCC
Daisy Chain cable required for PRO22ENC1, PRO22ENC2 and PRO22ENC5
PRO22E1PS 4-Amp rack-mounted power supply with battery backup required for PRO22ENC1, PRO22ENC2 and PRO22ENC5
Hardwired Kits
PRO22E1IC
Includes: PRO22ENC1, PRO22IC, PRO22E1PS, PRO22BAT1 and PRO22DCC
PRO22E2IC Includes: PRO22ENC2, PRO22IC, PRO22E1PS, PRO22BAT1 and PRO22DCC
Network Kits
PRO22E1EN
Includes: PRO22ENC1, PRO22IC, PRO22EN, PRO22E1PS, PRO22BAT1 and PRO22DCC
PRO22E2EN Includes: PRO22ENC2, PRO22IC, PRO22EN, PRO22E1PS, PRO22BAT1 and PRO22DCC
COMMON SPECIFICATIONS
Dimensions:
• Board: 9.0" H x 5.5" W x 1.0" D / 228.6 mm H x
1
39.7 mm W x 25.4 mm D
• PRO22ENC1: 13.9" H x 17" W x 9" D / 353 mm H x 431.8
mm W x 228.6 mm D
• PRO22ENC2: 13.9" H x 18.9" W x 9" D / 353 mm H x
480.06 mm W x 228.6 mm D
• PRO22ENC3: 14" H x 16" W x 4" D / 355.6 mm H x 406.4
mm W x 102 mm D
•
PRO22ENC4: 8.37" H x 7.63" W x 7.63 D / 212.8 mm H x
194 mm W x 194 mm D
• PRO22ENC5: 9.35" H x 16.85" W x 5.6" D / 237.4 mm H
x 427.9 mm W x 142.2 mm D
Enclosures:
• PRO22ENC1 (Wall-mount) Capacity:
- Nine modules. Power supply and battery not included
• PRO22ENC2 (19" Rack-mount) Capacity:
- Nine modules. Power supply and battery not included
• PRO22ENC3 (Tile-mount) Capacity:
- Two modules. Power supply and battery included
• PRO22ENC4 (Tile-mount) Capacity:
- One module (PRO22R1 only) Power supply and battery
i
ncluded
• PRO22ENC5 (Cage only for custom enclosures) Capacity:
-
Nine modules. Power supply and battery not included
Environment:
• Temperature: 0 to 70° C operational: -55 to 85° C storage
• Humidity: 0 to 95% RHNC
Wire Requirements:
• Power - twisted pair, 18 AWG
• RS-485 - 24 AWG, 4,000 ft. / 1,200 m max, two twisted
pairs with shield (120W, 23pF, Belden 9842 or equiv.)
• RS-232 - 24 AWG, 25 ft. / 7.6 m max.
• Alarm input - twisted pair, 30 ohms max.
