2
TABLE 2—R7795 MODELS AVAILABLE.
Flame Flame Establishing Flame Failure
Detection Amplifier Period (sec) Nominal Device Run/Test
R7795 Type Color Pilot
a
Main Response (sec) Reaction
b
Switch
R7795A UV Purple Intermittent Intermittent 3 Recycle No
Pilot or Lockout
R7795B Rectification Green
R7795C UV Purple 10/4 10 Yes
R7795D Rectification Green Interrupted Seconds
a
Field selectable:
10 sec with the orange jumper wire unclipped.
4 sec with the orange jumper wire clipped.
b
Field selectable:
Recycle with the yellow jumper wire unclipped.
Lockout with the yellow jumper wire clipped.
R7795A,B,C,D
SPECIFICATIONS • ORDERING INFORMATION
Specifications
Ordering Information
When purchasing replacement and modernization products from your TRADELINE® wholesaler or your distributor, refer to the
TRADELINE Catalog or price sheets for complete ordering number, or specify—
1. Order number, TRADELINE, if desired.
If you have additional questions, need further information, or would like to comment on our products or services, please write or
phone:
1. Your local Honeywell Home and Building Control Sales Office (check white pages of phone directory).
2. Home and Building Control Customer Satisfaction
Honeywell Inc., 1885 Douglas Drive North
Minneapolis, Minnesota 55422-4386 (612) 951-1000
In Canada—Honeywell Limited/Honeywell Limitée, 740 Ellesmere Road, Scarborough, Ontario M1P 2V9. International
Sales and Service Offices in all principal cities of the world. Manufacturing in Australia, Canada, Finland, France, Germany,
Japan, Mexico, Netherlands, Spain, Taiwan, United Kingdom, U.S.A.
TABLE 1—FLAME DETECTION SYSTEMS.
Flame Detection Applicable Flame Detectors
Model Amplifier Type Fuel Type Models
R7795A,C Ultraviolet (purple) Gas, oil UV (Minipeeper) C7027, C7035, C7044
R7795B,D Rectification (Green) Gas Rectifying flame rods Holders:
a
C7004,
C7007, C7011
Complete Assy:
C7005, C7008,
C7009, Q179
Oil Rectifying photo cells
b
C7003, C7010,
C7013, C7014
Gas, oil, coal UV (Purple Peeper) C7012A,C
a
Order flame rod separately.
b
Use Honeywell part no. 38316 Photocell only.
