9
LED Display
Media Button
The media button advances the paper through the printer. When
there is no paper in the printer, the button blinks red.
Icon Indication
Battery
charge
level
When not charging:
Off = Battery is midway to fully charged
Solid orange = Battery charge is 10-30%
Blinking red = Battery charge is 10% or less
When charging:
Solid green = Battery charge is 90% or more
Solid red = Battery charge is less than 90%
Bluetooth
indicator
Off = Bluetooth radio is off, disabled, not associated
with a mobile device, or printer is off
Blinking = Data transmission
Solid blue = Bluetooth is enabled and connected
WiFi
signal
Off = WiFi radio is off, disabled, not associated with a
mobile device or network, or printer is off
White = WiFi is enabled and connected
Button Press Result
Short press Feeds label or paper length
Press and hold (when configured for
continuous form receipt paper)
Media feeds continuously to
the maximum label length
