Advanced Installation Guide
Function 5: Heating cycle rate
Press the s or t button to select your heating system and optimize its
operation:
5 Gas or oil furnace: Use this setting if you have a standard gas or oil
furnace that is less than 90% efficient.
9 Electric furnace: Use this setting if you have any type of electric
heating system.
3 Hot water or high-efficiency furnace: Use this setting if you have a
hot water system or a gas furnace of greater than 90% efficiency.
1 Gas/oil steam or gravity system: Use this setting if you have a steam
or gravity heat system.
Press to change setting.
When correct setting is
selected, press NEXT to
display next function.
NOTE: If Function 5 does not appear, please
turn to the next page to continue.
