T7300F SERIES 2000 COMMERCIAL MICROELECTRONIC CONVENTIONAL
OR HEAT PUMP THERMOSTAT
Table 4. Installer System Test Options (Continued).
Key to
Press
Test
Number Description
Emergency Heating Equipment System Test (Q7300C,D,H [heat pump models only]).
Heat/Cool Settings 20 Change from heating to emergency heating equipment system test.
∆
21 Emergency heat and system fan turn on.
∆
22 Highest stage heat turns on.
∇
21 Highest stage heat turns off.
∇
20 Emergency heat turns off.
Cooling Equipment System Test
Heat/Cool Settings 30 Change from heating or emergency heating to cooling equipment system test.
∆
31 Stage-one cooling and system fan turn on.
∆
32 Stage-two cool turns on. Stage-one cool and system fan remain on.
∆
33 Stage-three cool turns on (Q7300G only). Stage-one and stage-two cool with
system fan remain on.
∇
32 Stage-three cool turns off.
∇
31 Stage-two cool turns off.
∇
30 Stage-one cool and system fan turn off.
Fan Equipment System Test
Heat/Cool Settings 40 Change from cooling to fan equipment system test.
∆
41 Fan turns on.
∇
40 Fan turns off.
Key Operation System Test
Heat/Cool Settings 60 2 Change from fan to key operation system test.
Unoccupied Temp 60 0 Unoccupied Temp test number is displayed.
Occupied Temp 60 1 Occupied Temp test number is displayed.
∆
60 3 Increase test number is displayed.
∇
60 5 Decrease test number is displayed.
Clear Start Time 60 7 Clear Start Time test number is displayed.
Day 60 8 Day test number is displayed.
Copy 60 9 Copy test number is displayed.
Unoccupied Start
TIme
60 10 Unoccupied Start Time test number is displayed.
System
(select models)
60 11 System test number is displayed.
Fan (select models) 60 12 Fan test number is displayed.
Set Current Day/Time 60 14 Set Current Day/Time test number is displayed.
Run Program 60 15 Run Program test number is displayed.
Temporary Occupied 60 16 Temporary Occupied test number is displayed .
Occupied Start Time 60 17 Occupied Start Time test number is displayed.
Continuous
Unoccupied
60 19 Continuous Unoccupied test number is displayed.
