T775L SERIES 2000 ELECTRONIC STAND-ALONE STAGING CONTROLLER
23 62-0257—11
Fig. 53. Program Menus - No Reset.
2.2. Program Menu for Outputs with No
Reset
From the Program menu, highlight the Loop or Relay
desired and press the button to view the parameters.
Fig. 53 shows both the Loop and Relay menus.
NOTE: The Setback parameter displays only if schedul-
ing is enabled (see Fig. 31 on page 15) or the DI
Option is set to Setback. (see Fig. 33 on
page 16).
Continue with “2.2.1. SETPOINT”.
Fig. 54. Program - Setpoint.
2.2.1. SETPOINT
1. From the menu, use the and buttons to high-
light SETPOINT.
2. Press the button to display the setpoint value.
3. Use the and buttons to increase/decrease the
desired setpoint temperature.
Default: 70°F (21°C)
Range: -40°F to 248°F (-40°C to 120°C)
4. Press the button to accept the setpoint tempera-
ture and display the next option.
Fig. 55. Program - Throttling Range or Differential.
2.2.2. THROTTLING RANGE or
DIFFERENTIAL
Throttling Range is used for Loops, and Differential
displays for the Relay outputs.
1. From the menu, use the and buttons to high-
light THROT RNG or DIFFRNTL.
2. Press the button to display the throttling range
value.
3. Use the and buttons to increase/decrease the
desired value.
Default: 20°F (-6.6°C)
Range: 1°F to 300°F (1°C to 149°C)
4. Press the button to accept the value and display
the next option.
The number of degrees selected for the throttling range is
divided between the number of stages. See page 11 for
staged operation.
In heating mode, the Differential is below the setpoint.
The relay de-energizes when the temperature rises to the
setpoint. As the temperature drops to the setpoint minus
the Differential, the relay energizes.
In cooling mode, the Differential is above the setpoint.
The relay de-energizes when the temperature falls to the
setpoint. As the temperature rises to the setpoint plus the
Differential, the relay energizes.
PROGRAM
LOOP 1
LOOPS MENU
MENU
PROGRAM
LOOP 1
SETPOINT
THROT RNG
SENSOR
HEAT/COOL
SETBACK
EXIT
ADDITIONAL RELAYS
MENU
MENU
PROGRAM
RELAY 9
SETPOINT
DIFFRNTL
SENSOR
HEAT/COOL
SETBACK
EXIT
M24421
PROGRAM
RELAY 9
ENTER
SETPOINT
FOR
LOOP 1
PROGRAM
LOOP 1
SETPOINT
MENU
PROGRAM
LOOP 1
SETPOINT
70
F
o
M24422
ENTER
THROTTLING
RANGE FOR
LOOP 1
PROGRAM
LOOP 1
THROT RNG
MENU
PROGRAM
LOOP 1
THROT RNG
20
F
o
M24423
To Next Page
