4. SCHEDULING T775U SERIES 2000 CONTROLLER
35 62-0255–05
Fig. 81. Schedule Event Menu (Showing MON-FRI).
4.3. Setting Individual Schedules
As shown in the Schedule menu (Fig. 76 on page 33),
schedules can be set for the following time periods:
• Monday through Friday
• Saturday and Sunday
• Individual days of the week
1. From the Schedule menu, use the S and T buttons
to highlight the desired time period.
2. Press the X button to display the Schedule menu
for the selected time period.
For each selected time period, the schedule event (E1
and E2) parameters are exactly the same as shown in
Fig. 81.
SCHEDULING EXAMPLE
Setting the schedule is independent of the temperature
settings for the relay outputs. Table 5 illustrates a weekly
schedule for daytime (setpoint) and night time (setback)
use and shows the factory default settings.
To set a schedule, continue with “4.3.1. E1 SETPT
(setpoint for event 1)”.
The following figures show the MON-FRI menu, but the
menu selections are the same for any time period.
Fig. 82. Schedule - Event 1 Setpoint.
4.3.1. E1 SETPT (setpoint for event 1)
1. From the selected time period menu, use the S and
T buttons to highlight E1 SETPT.
2. Press the X button to display the setpoint options.
3. Use the S and T buttons to highlight the desired
option.
4. Press the X button to accept the value and return to
the selected time period menu.
MENU
SCHEDULE
MON-FRI
MENU
SCHEDULE
MON-FRI
E1 SETPT
E1 TIME
E2 SETPT
E2 TIME
EXIT
M24625
Table 5. Mon-Fri Schedule Defaults
DAY EVENT SETPT ACTION TIME
Mon-Fri Event 1 (E1) Setpoint
6:00 AM
a
a
Setpoint time span is 6:00 AM until 5:59 PM because
setback starts at 6:00 PM.
Mon-Fri Event 2 (E2) Setback
6:00 PM
b
b
Setback time span is 6:00PM until 5:59 AM because
setpoint starts at 6:00 AM.
Sat-Sun Not used; remains in Setback from the
Mon-Fri E2 settings
MAIN
SCHEDULE
MON-FRI
E1 SETPT
MENU
SCHEDULE
MON-FRI
E1 SETPT
SELECT
SETPOINT
FOR
EVENT 1
SETPOINT
SETBACK
NOT USED
M24626
