Mounting and Operating Instructions Doorguard for MB panels BUS-2 41
9. Technical data
Operating unit
Operating voltage U_b 12 V DC
Operating voltage range 10 V DC to 15 V DC
Current consumption < 15 mA (average)
Detector group voltage 8 V DC
Detector group end-of-line resistor 12K1 or 10k (programmable, MB-Secure 4k to 14k6)
Monitoring range ±20%, ±30% or ±40% (programmable)
Output for acoustical alarm signalling 40 mA (active low)
Output for optical alarm signalling 40 mA (active low)
Transponder reader for IK2/proX1 and IK3/proX2 data carriers
Frequency range, Transmission power 125 kHz, <10 dBµA/m
Half cylinder as per DIN 18252 Standard dimension A = 30 mm, A = 35 mm possible
Operating temperature range -5 °C to +45 °C
Storage temperature range -25 ° C to +70 ° C
Environmental class as per VdS II
Protection class as per EN 60529 IP 40
Dimensions (W x H x D) 110 x 140 x 53 mm
Colour traffic white (similar to RAL 9016)
Alarm signalling device
Operating voltage range 9 V DC to 15 V DC
Current consumption - acoustical alarm Programming interval tone # 25 mA
Programming continuous tone # 50 mA
Current consumption - optical alarm # 25 mA
Acoustical alarm signalling Loudness level approx.100 dBA
Optical alarm signalling LED - flash interval approx. 1.5Hz
Operating temperature range -5 °C to +45 °C
Storage temperature range -25 ° C to +70 ° C
Environmental class as per VdS II
Protection class as per EN 60529 IP 40
Dimensions (W x H x D) 110 x 103 x 53 mm
Housing colour traffic white (similar to RAL 9016)
Hereby, the Novar GmbH declares that the radio equipment Doorguard for MB panels BUS-2, Item no.
041450.17 is in compliance with Directive 2014/53/EU.
The full text of the EU declaration can be downloaded from our homepage https://www.security.honeywell.de/ in the
service/download area.
