Installation
DIN rail
One Rod Flame Detection (special ignition transformer)
UV Flame Detection
Mounting plate
Pilot and Main firing control Double Rod for example)
UV sensor W white cable B blue cable
Dimension mm
Product Code
Timing
Code
T2 (sec)
T3 (sec)
1
3
1
2
5
1
3
10
1
4
3
2
5
5
2
6
10
2
Wiring diagram
Double Rod Flame Detection
Start-up signal
High voltage
Fault signal
Gas valve
Flame signal
Reset signal
Ignition transformer
Operation signal
Safety interlocks
