Honeywell V5004TF Series User Manual

GB
MU0H-2327GE23 R0618 3 Honeywell GmbH
1 Actuator's features
• Proportional control
• analogue (voltage and current), PWM, 3 points and ON/
OFF
• Position detecting
• 4-digit display
• 3 buttons to set parameters
• Position control method to set actuator
2 Installation Instructions
1. Mount the valve with the arrow in the direction of the
flow
CAUTION!
Mounting it in the wrong direction may damage the
system and the valve itself.
If flow reversal is possible, a non-return valve should be
mounted.
Minimum differential pressure above which the valve begins
to exercise its regulating effect:
2. To set the flow on the V5004TF use the digital display
and three buttons on the Smart actuator.
When it is switched on, the Zero Detection function
automatically starts: the display shows “Go 0“. Wait
while the actuator is running and the end stroke is
found: finally the display will change to “0”.
To enter the settings browser, press the button MODE.
Press UP and DOWN buttons to select the setting.
Press MODE to show different options and browse
using UP and DOWN buttons. Once the option is found,
press MODE to confirm as the selection.
Startup Pressure
OS-No. Flow [I/h] ∆ [kPa]
at 30%
flow
∆[kPa]
at 50%
flow
∆[kPa]
at 80% flow
∆[kPa]
at 100%
flow
∆[kPa]
V5004TF1050 2000 - 20000 21 25 31 40 600
V5004TF1065 3000 - 30000 26 29 30 30 600
V5004TF1080 3000 - 30000 23 25 30 30 600
V5004TF1100 5500 - 55000 16 20 24 30 600
V5004TF1125 9000 - 90000 21 25 31 35 600
V5004TF1150 15000 - 150000 31 35 41 50 600
V5004TF1200LF 20000 - 200000 31 35 36 40 400
V5004TF1200HF 30000 - 300000 32 37 38 40 400
V5004TF1250LF 30000 - 300000 30 30 33 40 400
V5004TF1250HF 50000 - 500000 38 49 58 65 400
SET1 Input indication selection with internal
control signal
SET2 Control signal selection
SET3 Min. flow rate setting
SET4 Max. flow rate setting
SET5 Setting display mode during operation
SET6 Rotation angle compensation
SET7 Flow rate offset compensation
SET8 Power failure mode
SET9 Flow rate unit selection
SET10 Control curve selection
SET11 Max. voltage control signal
SET12 Min. voltage control signal
SET13 Actuator rotation speed
SET14 Feedback signal selection
