69-2761EFS—03 4
Quick reference: commercial use
HOME. Touch to display Home screen.
FAN. Select fan mode.
SYSTEM. Select system mode (Heat/Cool).
MENU. Touch to display options. Start here to set a
program schedule.
Current status. Shows system mode (heat/cool),
outdoor temperature and humidity (with optional
outdoor sensor).
Override. Touch to override program schedule.
Current schedule. Touch an arrow to change
temperature setting and set a temporary hold.
Current program status.
Indoor conditions. Shows indoor temperature and
humidity.
Current time. Touch to set the current time/date.
Alert Light. On when alert message is active
or system is set to EmHeat. Flashes for battery-
only power; on continuous if system powered.
Micro SD Card port. Use card to load holiday
schedules and custom events.
The screen lights when you
press any button. It stays
lit for 7 seconds after you
complete changes. Depending
on how your thermostat was
installed, the screen light may
always be on.
