14
Project Properties
Close
New
The New icon in the menu bar is used for creating a project. The steps are as follows:
1. Select the menu command Project
New in the X-618 Config software window. The New
Project window is displayed, as shown in Figure 6.
2. Refer to the example shown in Figure 6 to set the Project name, Location, Device Group
Name and if set as the Central. The default directory for the project file is “My Documents”.
This direct path can be changed. Click the icon at the right side of the Location path field to
select a different directory.
Figure 6 New Project Window
3. Click the OK button to create the project. The window as shown in Figure 7 is displayed.
Figure 7 Project Created Sample
4. Right-clicking the mouse in the Project explorer view causes a menu to pop-up to add, rename,
or delete Group, and also to add, copy, paste, rename or delete Device.
Right-click Project Name, the Group can be added;
Right-click a Group, the devices of the Group can be added, pasted, renamed or deleted;
Right-click a device, the device can be copied, renamed or deleted, and another device
can be added or pasted.
