DOOR and FILTER
WARNING! When the tumble dryer is in use
the drum and door may be VERY HOT. Never
stop a tumble dryer before the end of the drying
cycle unless all items are quickly removed and
spread out so that the heat is dissipated.
Filter Care Indicator
DO NOT USE WATER TO CLEAN THE FILTER.
IMPORTANT: To maintain the efficiency of the
dryer check that the fluff filter is clean before
each drying cycle.
1 .
2.
3.
4 .
P u l l t h e f i l t e r
upwards.
Open filter as shown.
Gently remove lint
using a soft brush or
your fingertips.
S n a p t h e f i l t e r
together and push
back into place.
Lights when the
filter needs cleaning.
If the laundry is not
drying check that the
filter is not clogged.
Filter
12 EN
t
u e
WARNING! If you open the door mid cycle,
before the cool-down cycle has completed, he
handle may be hot. Please se xtreme caution
when attempting to empty the water reservoir
during the cycle.
To restart the dryer, close the door and press
Start / Pause button.
Pull on handle to open the door.
To Remove the Condenser
1. .
2.
Gently remove any dust or
fluff with a
5.Check the gasket position
after cleaning.Fit the gasket
in to the groove if it is
misaligned.
6.
7.
Remove the kickplate
Turn the two locking levers
anti-clockwise and pull out
the condenser.
3.Pull out the condenser unit.
4.
cloth, then wash
the unit by holding it under a
running tap turning it so that
water flows between the
plates, to remove any dust or
fluff.
Refit the condenser ensuring it
is in the correct way (as indicated
by the arrow) and pushed firmly
into place. Lock the two levers by
turning them clockwise.Be sure
that condenser unit fixed to the
basement tightly.
Refit the kickplate.
