Assemble the refrigerator door and freezer door to the opposite side
1. a． Remove the adjustable front foot as shown below by hand and then assemble the
lower hinge to the other side of the cabinet and fix the screws by using a tool.
b． Assemble the shorter adjustable front foot to the lower hinge side and adjust the height
of the foot to make the refrigerator stay in level.
2. Put on the freezer door and turn the middle hinge by 180 ℃ and then assemble it to the other
side of the cabinet; use a tool to screw up the 3 screws to fix the middle hinge.
3. Put on the refrigerator door and assemble the upper hinge to the other side of the cabinet;
use a tool to screw up the 4 screws to fix the upper hinge.
After that, connect the door communication line and the cabinet communication line and
then put on the upper hinge cover and fix it using a screw.
4. Assemble the hole cover to the other side of the cabinet and use a tool to screw up the hole
cover.
