48
c． Remove the adjustable front feet under the lower hinge; use a tool to remove the 4 screws
from the lower hinge and then disassemble the lower hinge. Door disassembly is finished.
Assemble door, lower hinge accessories to the corresponding positions
1. a． Use a tool to get the door bush out as shown in the below figure and assemble it to the
corresponding position of the other side.
b． Use a tool to remove the screws off the stopper ass as shown in the below figure and then
assemble them to the other side of the door.
c． Use a tool to remove the axle and two stoppers on the lower hinge and then assemble
them to the position as shown in the below figure.
This situation apply to open door in right side This situation apply to left side
