GENERAL MAINTENANCE
6. GENERAL MAINTENANCE
CLEANING FILTERS
Umbrella Tube
When to Clean
Check Umbrella tube on a monthly basis and clean
when it is wrapped with debris.
How to Clean
CAUTION - To reduce the risk of personal injury
- Unplug before cleaning or servicing. Do not
use cleaner without dirt cup or filters in place.
Remove dirt cup as described in Fig. 6.2.
6.10
Press red dirt cup door release button (C) to
open dirt cup door.
6.11
Twist Umbrella tube left and remove from
bottom of the dirt cup.
6.12
Hold filter over trash receptacle and remove
dirt and debris.
Replace Umbrella tube in bottom of dirt cup and
twist right.
6.10
6.11
6.12
C
