4-1
4-2
Allow brushes and underside of car-
pet cleaner to air dry thoroughly
before storing carpet cleaner on a
carpeted or wood surface.
Do not store carpet cleaner with a
full clean water tank in place.
Lubrication
The motor is equipped with bearings which
contain sufficient lubrication for the life of the
motor. The addition of lubricant could cause
damage. Do not add lubricant to motor
bearings.
4-3
A
A
B
B
C
D
3-23
Storage
Before storing:
• Empty clean water tank and let air
dry. Replace on carpet cleaner.
4. Maintenance
15
instructions for Figs. 2-13 to 2-14.
5. Attach tool to end of hose.
Do not point tools toward people or
pets.
6. Dry hands and plug carpet cleaner into a
properly grounded outlet.
7. Set Wash/Rinse switch to WASH. Turn
cleaner ON.
8. Gently press the tool onto the fabric. Press
the trigger and slowly pull the nozzle over the
fabric.
9. Overlap strokes by 1/2 inch to help pre-
vent streaking.
Make additional strokes without pressing the
trigger to remove more moisture.
10. To clean in corners or creases, lift the
tool one-half inch from the fabric and press
the solution trigger.
11. Vacuum up the solution with the tool with-
out pressing the trigger.
12. For heavily soiled areas, it may be neces-
sary to repeat the cleaning process. Make
crisscrossing strokes to the original pattern;
overlap each pass (Fig. 3-23).
Cleaning upholstery
3-22
Make no more than 2 passes with the
solution or rinse over any one area to
prevent over-wetting and damage to
fabric.
If additional cleaning is necessary, wait until
the upholstery is completely dry before using
the tool again.
13. Empty recovery tank when the motor
sound becomes higher pitched and there is
a loss in suction (see “Automatic shut-off”,
Fig. 2-6).
When finished cleaning, follow “After clean-
ing” instructions on pages 9 & 10 and “After
using tool” instructions on page 12.
Removable brushes
Your carpet cleaner is equipped with remov-
able brushes for easy cleaning.
To remove brushes
Disconnect cleaner from electrical
outlet.
To prevent possible leaking, remove clean
water tank and recovery tank. Set tanks
aside.
With handle in upright position, tilt cleaner
back until handle rests on the floor.
Grab brush assembly and pull firmly.
The brushes can be cleaned under running
water.
To replace brushes
Align posts (A) on both ends of brush assem-
bly with slots (B) in cleaner housing.
Make sure that the square post (C) also
aligns with the square hole (D). Turn brushes
slightly until post fits easily into hole.
Press brush assembly firmly to snap into
place.
• Unused detergent can be stored in
the detergent container.
• Empty recovery tank, rinse tank
and lid thoroughly with clean water
and let air dry.
Continued ➜
