7
Push switch (A) once to turn cleaner
ON. Push switch again to turn
cleaner OFF.
A
14
ON/OFF switch
A
13
Handle release pedal
Step on pedal (A) to lower handle
to operating position. Handle does
not lock into a single position, but
“floats” to allow convenient operation.
B
B
E
J
J
I
H
F
G
D
C
A
A
12
Unfold handle
Raise upper handle (A) to upright
position until it locks in place.
11
How to fold handle
Press upper handle release button
(B) to fold handle to storage position.
11
12
13
14
To store hose: Place the hose grip (A) into
slot (B) on back of caddy. Pull hose up and
press into cut-out area (C). Continue wrap-
ping hose down, underneath tongue (D), and
back up, pressing into second cut-out area (E).
Place hose end (F) into slot (G) on back of caddy.
Place floor swivel tool (H), telescoping wand (I)
and detergent (J) into caddy as shown.
10
10
Store hose, tools and accessories
