1. GETTING TO KNOW YOUR CLEANER
MAIN COMPONENTS:
A. BATTERY PACK
B. BATTER PACK RELEASE BUTTONS
C. BATTERY CHARGER INLET
D. ON/OFF POWER BUTTON
E. POWER MODE BUTTON
F. BATTERY STATUS LED
G. DUST BIN ULTRA COMPACT X3 SLIDER
H. DUST BIN
I. DUST BIN REMOVAL LEVER
J. DUST BIN EMPTY RELEASE BUTTON
K. TUBE RELEASE BUTTON
L. TUBE
M. NOZZLE RELEASE BUTTON
N. FLOOR NOZZLE
O. NOZZLE BRUSHBAR RELEASE SLIDER
P. NOZZLE BRUSHBAR RELEASE LATCH
Q. NOZZLE WINDOW
R. NOZZLE BRUSHBAR
S. WALL MOUNT
T. WALL MOUNT SCREWS & FIXINGS
U. CHARGER
V. MINI POWER NOZZLE*
W. CREVICE TOOL
X. ADDITIONAL BATTERY PACK*
* Dependant on your model.
X
S T U V W
A
N
Q
G
H
L
M
GB
FED
O
R
P
J
I
K
B
C
