12
CLEANING THE BRUSH ROLL AND NOZZLE (CONT.)
To reassemble, align brush roll
onto the gear and lock into place
by pressing down on the tab end.
If needed, rinse brush roll cover
and wipe any remaining residue
from the brush roll chamber
and hose. Allow to dry before
returning to the cleaner.
Replace brush roll cover. Ensure
that the corners are down and
the brush roll cover is fully in
place.
Lift up on the tab to remove the
brush roll. Place in rack on
storage tray and allow to dry
completely before reinstalling.
After rinsing, remove the nozzle
cover by squeezing the latches
and lifting up.
321
4 5
