Dirt cup assembly
13
Insert the filter into
dirt cup. Make sure
the filter is locked
into position on
either sides.
Install the Dirt Cup.Attach the fan
assembly.
1 32
CAUTION
To reduce the risk of personal
i n j u r y - Tu r n p o w e r s w i t c h O F F b e f o r e
cleaning or servicing.
! !
