5
1. set-uP & HoW to use
PRoduCt desCRiPtion
BACK/FRONT
1. Rear Grille
2. Rinsable Pre-Filter
3. Replacement filter made
with HEPA Media
4. TiO
2
Coated Screen
5. UV Bulb
CONTROL PANEL
6. UV Bulb/ TiO
2
Coated Screen
7. Ionizer
8. 1 to 24 Hour Timer
9. 3 Speed Control with Auto
10. LCD Display
11. Filter Reset
LCD DISPLAY ICON
a. IONIZER on
b. UV/TiO
2
on
c. Filter made with HEPA Media
Replacement Indicator
d. Timer (Time Left)
e. Running Fan Speed/
IntelliSense
TM
Control System*
(“A” for Auto Mode)
*Setting the unit on AUTO mode (A) will allow the unit to run at the most effective speed based on readings
from the air quality monitor. As air conditions change, the air purifier will change its fan speed setting
accordingly. This reading will be clearly represented by a change in the background color of the LCD
screen. Blue = Good air quality, Amber = Fair air quality, Red =Poor air quality. For proper function, ensure
that there is adequate airflow around the product.
1
1.1
BACK FRONT
CONTROL PANEL
2
3
5
7
8
6
10
9
a
b
c
d
e
4
set-uP
- Remove the air purifier from its packaging.
IMPORTANT
Place the unit on a flat, stable surface with
adequate ventilation.
- Plug the unit into an AC outlet.
- Press the POWER button.
- Adjust the Air Cleaning Power with the “+” and “-“
buttons. The unit has three Air Cleaning Power
settings, and an Auto Mode.
- Press the “UV/TiO
2
” button to toggle on/off.
The curved light at the front of the unit will
illuminate when the UV/TiO
2
mode has been
activated.
- Press the “ION” button to toggle on/off. The
button will illuminate with an amber light when
the ION mode has been activated.
- Press the TIMER button to set the timer to 1 to
24 hours/OFF (hours indicated with LCD
display).
11
