Horizon Hobby Cirrus SR22T User Manual

EN
3
SAFE
®
Select Technology ...................................................................4
Prefl ight .............................................................................................4
Transmitter Setup .............................................................................4
Model Assembly ................................................................................5
Transmitter and Receiver Binding / SAFE Select .................................6
Battery Installation and ESC Arming ...................................................7
Model Assembly Continued ................................................................ 8
Scale Accessories Optional ................................................................9
SAFE
®
Select Switch Designation ......................................................9
Control Horn and Servo Arm Settings .................................................9
Center of Gravity (CG) .....................................................................10
AS3X Control Direction Test .............................................................10
In Flight Trimming ............................................................................10
Flying Tips and Repairs ....................................................................11
PNP Receiver Selection and Installation ...........................................11
Post Flight .......................................................................................12
Motor Service ..................................................................................12
Troubleshooting Guide AS3X ............................................................12
Troubleshooting Guide .....................................................................13
AMA National Model Aircraft Safety Code .........................................14
Limited Warranty .............................................................................15
Contact Information .........................................................................16
FCC Information ...............................................................................16
IC Information ..................................................................................16
Compliance Information for the European Union ...............................16
Replacement Parts ...........................................................................59
Optional Parts ..................................................................................60
If you own this product, you may be required to register with the FAA.
For up-to-date information on how to register with the FAA, visit https://
registermyuas.faa.gov/.
For additional assistance on regulations and guidance on UAS usage, visit
knowbeforeyoufl y.org/.
To register your product online, visit www.e-fl iterc.com
Box Contents
Quick Start Information
Transmitter
Setup
Set up your transmitter using the
transmitter setup chart
Dual Rates
Hi Rate Low Rate
Ail
25mm
25mm
15mm
15mm
Ele
11mm 9mm
Rud
16mm 10mm
Flaps
Landing
=30mm
Takeoff
=15mm
Center of
Gravity (CG)
63.5mm +/-3mm back from leading edge
of wing at the fuselage.
Flight Timer
Setting
4 minutes
Table of Contents
Specifi cations
Motor: Motor 10 1300Kv
(EFLM108018)
Installed Installed
ESC: 40A ESC (EFLA1040U) Installed Installed
9 gram servo (SPMSA330R) Installed Installed
Receiver: Spektrum
™
AR636A
6-Channel Sport Receiver
(SMPAR636A)
Installed
Required
to
Complete
Recommended Battery: 11.1V
3S 2200-3200mAh 30C Li-Po
(EFLB22003S30, EFLB32003S30)
Required
to
Complete
Required
to
Complete
Recommended Battery Charger:
3-cell Li-Po battery balancing
charger
Required
to
Complete
Required
to
Complete
Recommended Transmitter:
Full-Range 6 channel (or more)
2.4GHz with Spektrum
DSM2
®
/DSMX
®
technology with
adjustable Dual Rates
Required
to
Complete
Required
to
Complete
S
P
T
M
T
B
M
S
S
C
C
A
I
F
P
P
M
T
T
A
L
C
F
I
C
R
O
I
f
F
r
F
k
T
59 in (1498mm)
39 in (1000mm)
53-61 oz
(1500 - 1700g)
369 sq/in
(23.81 sq/dm)
