Prerequisites
The warranty claim only applies in the country where the
equipment was purchased. The product must have been
purchased through our authorised distribution channels.
A claim under this warranty exists only for damage to the
object of the contract itself. Reimbursement of expenditure
for dismantling and fitting, testing of parts as well as demands
for lost profits and compensation for damages are excluded
from the warranty.
The receipt of purchase substantiates your right to claim
under the warranty.
Performance12.1
For the duration of the warranty we shall eliminate any
product defects that are proven to be attributable to
a material or manufacturing fault. We pledge to replace free
of charge and at our discretion the defective goods with
non-defective goods, to carry out repairs or to grant a price
reduction.
Damages caused by the following are excluded:
improper fitting and connectionō
improper initial start-up and operationō
external factors such as fire, water, abnormal ō
environmental conditions
mechanical damage caused by accidents, falls, impactsō
negligent or intentional destructionō
normal wear or deficient maintenanceō
repairs conducted by unqualified personsō
use of non-original partsō
removal or defacing of the data labelō
Replaced parts become our property.
Excerpt from the Declaration 13
of Incorporation
(as defined in EC Machinery Directive 2006/42/EC for
incorporation of partly completed machinery according to
annex II, part B).
The product described on the reverse side has been
developed, constructed and produced in accordance with:
EC Machinery Directive 2006/42 ECō
EC Construction Products Directive 89/106/EECō
EC Low-Voltage Directive 2006/95/ECō
EC Electromagnetic Compatibility Directive 2004/108/ECō
Applied and consulted standards:
EN ISO 13849-1, PL “c”, Cat. 2 ō
Safety of machinery – Safety-related parts of control
systems – Part 1: General principles
EN 60335-1/2, when applicable ō
Safety of electrical appliances / Operators for doors
EN 61000-6-3 ō
Electromagnetic compatibility – Electromagnetic radiation
EN 61000-6-2 ō
Electromagnetic Compatibility – Interference immunity
Partly completed machinery as defined in the EC Directive
2006/42/EC is only intended to be incorporated into or
assembled with other machinery or other partly completed
machinery or equipment, thereby forming machinery to which
this directive applies.
This is why this product must only be put into operation after
it has been determined that the entire machine / system in
which it was installed corresponds with the guidelines of the
EC directive mentioned above.
Technical data14
External dimensions: 275 x 140 x 90 mm
Mains voltage: 230/240 V, 50/60 Hz,
stand-by approx. 6 W
Protection category: Only for dry rooms
Temperature range: -20°C to +60°C
Replacement bulb: Candle bulb E14, 240 V,
max. 25 W
Fuse for control current
circuit:
Microfuse 5 x 20 mm, 2 A
Motor: Direct current motor with
hall sensor
Transformer: With thermal protection
Connection: No-screw connection
technology for external
equipment with 24 V DC low
safety voltage, such as internal
and external buttons with
impulse operation.
Remote control: Operation with internal or
external radio receiver
Automatic cut-out: Is automatically taught in for
both directions separately.
Self-learning, wear-free, as it
has no mechanical switches.
Travel / power limit Readjusting automatic safety
cut-out for every door run.
Door travel speed: Approx. 11 cm/s (depending
on door size, door weight and
barrel diameter)
Rated load: See data label
Pull and push force: See data label
Short-term peak load: See data label
Special functions: Operator light, 2-minute ō
light ex factory
Photocell can be ō
connected
Option relay for warning ō
lamp
Signal tone generator for ō
forced opening attempt
Battery can be connected ō
for emergency operation
External releaseō
Emergency release: Actuated from inside with pull
cord in the event of a power
failure
Airborne sound
emission of the garage
door operator:
≤ 70 dB (A)
Door cycles: See product information
TR10A073-B RE / 02.2012 33
