Overview of DIL switch functions15
DIL 1 Set-up mode / press-and-hold operation and normal operation
OFF Not activated, set-up mode / press-and-hold operation for door fitting
ON Activated, normal operation in press-and-release operation
Automatic timer, pre-warning phase
DIL 2 DIL 3 DIL 4 Operator
function
Operator light function Option relay function
OFF OFF OFF – Permanent light during the door
run / switch-off delay after end-
of-travel positions have been
reached
Same function as operator light
(external light)
ON OFF OFF – Flashes quickly in the ō
pre-warning phase
Permanent light during the ō
door run
Relay clocks slowly during the
door run (function of an
auto-flashing warning lamp)
OFF ON OFF – Permanent light during the door
run / switch-off delay after end-
of-travel positions have been
reached
Close limit switch reporting
ON ON ON Automatic timer Permanent light during the ō
hold-open phase and the
door run
Flashes quickly during the ō
pre-warning phase
Permanent contact during the ō
hold-open phase
Clocks rapidly during the ō
pre-warning phase and
slowly during the door run
DIL 4 Photocell (e.g. EL 101, EL 301)
OFF Not activated, automatic timer not possible
ON Activated, if the photocell is activated, the door reverses to the OPEN end-of-travel position.
Automatic timer is only possible with this setting.
DIL 5 Optional safety equipment (OSE)
OFF Without safety equipment (OSE), normal door operation
ON No closing possible without the safety equipment (OSE)
DIL 6 Door maintenance display
OFF Not activated, no signal after the maintenance cycle is exceeded
ON Activated; if the maintenance cycle is exceeded, this is signalled by the operator light flashing several times
at the end of every door run.
34
TR10A073-B RE / 02.2012
ENGLISH
