Overview of errors and troubleshooting16
Display Error / warning Possible cause Remedy
Safety equipment Photocell was interrupted, is not connected. Check photocell, replace
▶
or connect as necessary
(see Figure 8).
Power limit in Close
direction
Obstacle in door area. Remove the obstacle.
▶
Delete any door data and
▶
teach in again
(see section 4.2).
Static current circuit The static current circuit (RSK, see section 3.4)
is open.
Check the connected
▶
units, close the circuit
(see section 3.4).
Power limit in OPEN
direction
Obstacle in door area. Remove the obstacle.
▶
Delete any door data and
▶
teach in again
(see section 4.2).
Operator error Malfunction in operator system Delete door data, replace
▶
operator if this recurs
several times
(see section 4.2).
Operator error
Message, no fault
The operator has not been taught in yet. Teach in the operator
▶
(see section 4.1.2).
No reference point
Power failure,
mechanical locking
The operator requires an Open reference run. Reference run in the
▶
Open
direction (see section 6.7).
Emergency battery
voltage
Voltage of emergency battery is too low. Further electrical
▶
operation is possible only
after the mains voltage
has been restored
(see section 3.3.5).
Connecting cables Connection to the motor connection circuit board
in the operator is defective.
Check the connection and
▶
connection cables.
Exchange the motor
▶
connection circuit board.
TR10A073-B RE / 02.2012 35
