Fitting4.1.1
All DIL switches 1. must be OFF.
Insert the control plug into the electric socket or activate 2.
the electrical fixed connection (see section 3.2.1).
The rim of the large T button flashes quickly.
In press-and-hold operation (alternating Open - Close - 3.
Open - Close....as long as the button is held down), the
curtain can now be rolled onto the shaft and, by moving
up and down, fed into the side guide.
After fixing the curtain as specified in the “Instructions for 4.
Fitting, Operating and Maintenance, Roller Garage Door”,
check several times whether the door runs correctly.
Close the door halfway.5.
NOTE:
Check whether the grip handles (fixed) are fitted to the bottom
weather seal.
4.1.2 Teaching in
See Figure
▶
11
DIL switch 11. to ON.
The rim of the large T button flashes 7x - pause - 7x -
pause - etc. to show that the “operator has not been
taught in yet”.
Press the large 2. T button 1x.
The Open reference run takes place automatically,
followed by two Close / Open cycles to teach in the Close
end-of-travel position and the forces. When the door
stops in the Open end-of-travel position and the rim of
the large T button flashes, the operator has been taught
in.
Switch the control voltage-free and complete the 3.
remainder of the mechanical fitting as described in the
“Instructions for Fitting, Operation and Maintenance,
Roller Garage Door”.
Set DIL switches 2-64. according to the additional
functions (see section 4.3.2 - 4.3.5).
4.2 Factory reset
The operator has a power failure-proof memory in which the
door-specific data (travel, forces needed during door
travel, etc.) is stored during the teach-in process and updated
during subsequent door travels. This data is only valid for this
door. For use with another door, or if the door's travel
behaviour has changed significantly (i.e. new springs,
conversions etc.), this data must be deleted and the operator
must be taught in again.
Reset and teach in the operator again
The door should be in the centre.1.
Push and hold down the 2. RESET button for at least 5
seconds (see Figure 1.3), the rim of the large T button will
flash quickly. When the rim of the large T button remains
lit, release the RESET button.
All door data has been deleted. The rim of the large
T button flashes 7x - pause - 7x - pause - etc. to show
that the “operator has not been taught in yet”.
Press the large 3. T button 1x. The Open reference run
takes place automatically, followed by two Close / Open
cycles to teach in the Close end-of-travel position and
the forces.
When the door stops in the OPEN end-of-travel position
and the rim of the large T button flashes, the operator
has been taught in.
WARNING
Danger of injuries due to faulty safety equipment
In the event of a malfunction, there is a danger of injuries
due to faulty safety equipment.
After the learning runs, the person commissioning
▶
the door must check the function(s) of the safety
equipment as well as the settings (see section 4.3).
The system is ready for operation only after this.
4.3 Setting additional functions via the DIL switches
Several of the operator's functions must be programmed
using the DIL switches. Before initial start-up, the DIL
switches are in factory settings, i.e. the switches are in the
OFF position (see Figure 1.2).
DIL switches 1 to 6 (accessible under flap of operator cover,
see Figure 1.1) must be set in accordance with the national
regulations, the desired safety equipment and on-site
circumstances.
Changes to the DIL switch settings are only permissible if the
operator is idling and no pre-warning phase or automatic
timer is active.
4.3.1 DIL switch 1
Set-up mode / press-and-hold operation and
normal operation
See section
▶
4.1.2
1 ON Activated, normal operation in press-and-release
operation
1 OFF
Not activated, set-up mode / press-and-hold
operation for door fitting
4.3.2 DIL switch 2 / DIL switch 3
The functions of the operator (automatic timer / pre-warning
phase) and the function of the option relay are set with
DIL switch 2 in combination with DIL switch 3.
Automatic timer, pre-warning phase
2 ON 3 ON Operator function
After hold-open phase and pre-warning
phase, automatic timer from the Open
end-of-travel position
(DIL switch 4 to ON)
Operator light
Permanent light during the hold-open ō
phase and door run
Flashes quickly during the ō
pre-warning phase
Option relay
Permanent contact during the ō
hold-open phase
Clocks rapidly during the ō
pre-warning phase and slowly during
door run
26
TR10A073-B RE / 02.2012
ENGLISH
