6
TR10A108-B RE / 02.2013
Safety instructions for fitting2.5
The specialist carrying out the work must ensure that
installation is conducted in compliance with the prevailing
occupational safety rules and regulations and those governing
the operation of electrical equipment. The relevant national
guidelines must be observed. Potential hazards as outlined in
DIN EN 13241-1 are avoided by the construction and fitting
according to our guidelines.
The garage ceiling must guarantee secure fastening of the
operator. For ceilings which are too high or too light, the
operator must be fastened with additional struts.
WARNING
Unsuitable fixing material
See warning in section
▶
3.3
Danger to life from the pull rope
See warning in section
▶
3.3
Danger of injury due to unwanted door travel
See warning in section
▶
3.3
2.6 Safety instructions for initial start-up and for
operation
DANGER
Mains voltage
Contact with the mains voltage presents the danger of a
deadly electric shock.
For that reason, observe the following warnings under all
circumstances:
Electrical connections may only be made by a qualified
▶
electrician.
The on-site electrical installation must conform to the
▶
applicable protective regulations (230 / 240 V AC,
50 / 60 Hz)!
The mains plug must be disconnected before any work
▶
is performed on the operator.
WARNING
Danger of injury during door travel
See warning in section
▶
5
CAUTION
Danger of injury due to selection of the wrong door type
See warning in section
▶
7
CAUTION
Danger of crushing in the boom
See warning in section
▶
10
Danger of injury from the cord knob
See warning in section
▶
10
Danger of injury due to the hot lamp
See warning in section
▶
11.2
Danger of injury resulting from uncontrolled door
movement in the Close direction if one of the
counterbalance springs breaks and the slide carriage is
released.
See warning in section
▶
10
ATTENTION
External voltage at the connecting terminals
External voltage on the connecting terminals of the control
will destroy the electronics.
Do not apply any mains voltage (230 / 240 V AC) to the
▶
connecting terminals of the control.
Safety instructions for using the hand 2.7
transmitter
WARNING
Danger of injury during door travel
See warning in section
▶
8
CAUTION
Danger of injury due to unintended door travel
See warning in section
▶
8
CAUTION
Danger of burns from the hand transmitter
See warning in section
▶
8
2.8 Approved safety equipment
Safety relevant functions or components of the control from
our company, such as the power limit, external photocells /
switching strips, have been designed and approved in
accordance with category 2, PL “c” of EN ISO 13849-1:2008.
WARNING
Danger of injury due to faulty safety equipment
See warning in section
▶
7
ENGLISH
