Hornady LOCK-N-LOAD - Assembly: AP Press; Lock-N-Load AP Reloading Press PARTS LIST

Item No.
Production
Part No. Qty. Description
1 398318 1 Support Primer Tube
2 398356 1 Tube Primer Pickup, Large
3 398355 1 Tube Primer Pickup, Small
4 398358 1 Tube Primer, Large
5 398357 1 Tube Primer, Small
6 398322 1 Housing Tube Primer
7 392220 1 Screw, BHCS 1/4-20 X 1/2
8 399686 1 Lock-N-Load
®
AP Bracket
9 392342 1 SHCS SS 3/8-16 X 3/4
10 398359 1 Primer Follower
11 392338 1 Screw, SHCS 10-24 X 1/2
12 — Shell Plate (Sold Separately)
13 392455 1 Bracket Box Cartridge
14 398319A 1 Housing Body Primer Tube
15 392218 1 Primer Slide, Large Assembly
15 392219 1 Primer Slide, Small Assembly
16 392336 1 Spring Primer Slide
17 392363 1 Spring Case Retainer
18 398695 1 AP Breakaway Cam Wire
19 398698 1 Nut, 8-32
20 190216 1 Frame
21 392368 6 Clip C, C-50
22 480039 1 Box Catcher
23 392408 2 Lock-N-Load
®
AP
™
Link
24 398309T 1 Sub Plate
26 398505 1 Primer Seater Punch, Small
26 398507 1 Primer Seater Punch, Large
27 392467 1 Counter Balance Spring
28 392345 1 3/8 Flat Washer SS
29 392355 1 Drive Hub
Item No.
Production
Part No. Qty. Description
30 392356 1 Drive Shaft
31 392231 2 Screw, BHSCS 8-32 X 3/8
32 392344A 2 Pawl
33 392423 2 Spring Pawl
34 392306 2 Dowel Pin 1/8 X 1/2
35 392221 2 Screw, FHCS 1/4-28 X 3/8
36 290029 1 Spent Primer Tube
37 398163 1 Ram Assembly
38 398422 3 Grease Zerk™
39 392343 1 Toggle
40 392340 1 Pin Yoke
41 392424 5 Spring Washer
42 392417 2 Pin Link Toggle
43 390027 1 Nut Jam, 5/8-18
44 390657 1 Handle
45 480003 1 Knob
47 392358A 1 Index Wheel
48 390081 2 Clip E 1/2
49 392302 5 Lock-N-Load
®
Bushing, Male
50 392303 5 Lock-N-Load
®
Bushing O-Ring
51 392301 5 Lock-N-Load
®
Bushing, Female
52 398697 1 Breakaway Cam Plunger
53 398696 1 Breakaway Cam Wire Spring
54 399853 1 Spent Primer Hose Clamp
55 392365 1 Spent Primer PVC Tube
56 399850 1 Spent Primer Bottle Barbed Fitting
57 399851 1 Spent Primer Bottle Cap
58 399852 1 Spent Primer Bottle
— 9987 1 DVD
Lock-N-Load
®
Auto Progressive (AP) Reloading Press
PARTS LIST
No-Risk Lifetime Warranty
All Hornady reloading tools and accessories are warranted against material defects and workmanship
for the life of the product. Simply stated – if it breaks, we’ll repair it or replace it at no charge
(at Hornady Manufacturing Company’s option).
Hornady reloading tools and accessories are warranted against defective materials and workmanship
only. This warranty is void if the product (1) has been damaged by accident or unreasonable use, neglect, improper service or other
causes not arising out of defects in material or workmanship; or (2) has been altered or repairs have been made or attempted by
other than authorized factory personnel; (3) is used commercially; or (4) has been altered or defaced in any way.
This warranty supersedes all other warranties for Hornady products either written or oral. No other warranty is expressed or implied.
- 4 -
ASSEMBLY: AP PRESS
ASSEMBLY
