TECHNICAL SPECIFICATIONS
General Specifications
PrimaryPowerRange 10-30VDC
Max.Current
500mA,Class2
750mA,Class2withheater*
RequiredPower
(SteadyState)
130mA@24VDC
InrushCurrent 30Afor<1ms
Typicalpowerback-
light100%
136mA@10V(1.36W)
64mA@24V(1.53W)
PowerBacklightOff 15mA@24V(0.36W)
PowerEthernet
Models
35mA@10V(0.35W)
20mA@24V(0.48W)
HeaterOption* 250mA@24VDCwithheater*
RealTimeClock
Batterybacked;lithiumcoincell
CR2450
ClockAccuracy +/-90Secs/Month
RelativeHumidity 5to95%Non-condensing
OperatingTemp. -10°Cto+60°C
StorageTemp. -20°Cto+70°C
Weight 0.75lbs/340g(withoutI/O)
Altitude Upto2000m
RatedPollution
Degree
EvaluatedforPollutionDegree2
Rating
Certifications(UL/CE) NorthAmericaorEurope
EnclosureType 1,3R,4,4X,12,12K&13
*HeaterOption(Model#plus"-22")

Control and Logic
ControlLang.
Support
Register-BasedAdvancedLad-
der;
Variable-BasedAdvancedLad-
der;
IEC61131-3Languages
LogicProgramSize 256kB
ScanRate
0.7ms/kBlogic(XLE)
0.8ms/kBlogic(XLT)
DigitalInputs 2048
DigitalOutputs 2048
AnalogInputs 512
AnalogOutputs 512
Gen.Purpose
Registers
9,999(words)Retentive
2,048(bits)Retentive
2,048(bits)Non-retentive



User Interface
DisplayType
TransflectiveLCDSun-light
Readable
Resolution
128x64pixels(XLEe)
160x128pixels(XLTe)
Color Monochrome
Built-InStorage 16MB
User-Program.
Screens
1023maxpages;
50objectsperpage
Backlight LED
BacklightLifetime 30,000+hrs
BrightnessControl
0-100%(XLT)
On/Off(XLE)via
SystemRegister%SR57
NumberofKeys
20(XLE)
5(XLT)
Touchscreen(XLTe) Resistive1,000,000+touchlife


Connectivity
SerialPorts
RS-232fullhandshakingorRS-
485halfduplexonfirstModular
Jack(MJ1)
RS-232orRS-485onsecond
ModularJack(MJ2)
USBMini-B Programmingonly
CAN 1xCANPort,Isolated1kV
CAN
Protocols
CsCAN,CANopen,DeviceNet,
J1939
Ethernet
Ethernetversionsonly
(XLEe&XLTe)
Ethernet
Protocols
TCP/IP,ModbusTCP,FTP,
SRTP,EGD,ICMP,ASCII
RemoteI/O
SmartRail,SmartStix,
SmartBlock,SmartMod
RemovableMemory
MicroSD,SDHC,SDXC,IN
FAT32format,supportfor32GB
max.ApplicationUpdates,
Datalogging
Audio
(XLTeonly)
Beeper,Systemor
SoftwareControlled
