Instruction Manual
Microprocessor Temperature Regulator HT MC11
Page 16 of 22
H P prop. band (P)
"heating" >PID<
OF F 0.1 … 100% <3.0>
If OFF , next visible parameter: H Sd
H d rate (D) "heating"
>PID<
OF F 1 … 200 s <30>
H
j
reset (I) "heating"
>PID<
OF F 1 … 1000 s <150>
H Cy
cycle time "heating"
>PID<
0.5 … 240.0 s <0.5>
Cycle time specifies the switching frequency of the actuator.
In this period the controller switches on and off once.
Voltage outputs for SSRs:
cycle time: 0.5...10 s
optimal value for fast control loops: 0.8 s
Relay outputs:
cycle time: > 15 s
The adjusted cycle time should be as long as possible to mini-
mize the wear of the relay contacts.
C P prop. band (P)
"cooling" >PID<
Factory setting, not applicable
C d rate (D) "cooling"
>PID<
Factory setting, not applicable
C
j
reset (I) "cooling"
>PID<
Factory setting, not applicable
C Cy cycle time "cooling"
>PID<
Factory setting, not applicable
C S d switching sensitivity
"cooling" >PID<
Factory setting, not applicable
Version 1080/1.03 02/2018
471 10 1400
