Instruction Manual
Microprocessor Temperature Regulator HT MC11
Page 20 of 22
E n d . P
Behavior after program has
finished
S P . 1
Control operation with actual setpoint.
Normally: Setpoint 1.
LA S t
Control operation with setpoint of last step
rE P t
Restart program beginning with first step.
I. r A
Step 1 Ramp time
0 ... 6000 min
In this time interval the setpoint runs linearly from the last step
temperature to the setpoint of the actual step.
First step starts with actual process value.
*Switch off ramp function by setting value to 0 min.
I. S P
Step 1 Ramp setpoint
S P . L o … SP.H i
Setpoint for this step.
I. t i
Step 1 Dwell time
0 ... 6000 min
The dwell time starts after the ramp has finished. The con-
troller works using the ramp setpoint for this time.
If behavior at end of a ramp phase E n d . S is set to t E nP ,
dwell time does not start before the ramp setpoint has been
reached.
… …
6. r A
Step 6 Ramp time
0 ... 6000 min
6. S P
Step 6 Ramp setpoint
S P . L o … SP.H i
6. t i
Step 6 Dwell time
0 ... 6000 min
Please note: installed heating power can be insufficient to realize programmed tem-
perature ramp.
Version 1080/1.03 02/2018
471 10 1400
